DIP Din 41612 Connector 2.54mm 16 Pin Male Pins Connector 3AMP Rated Current

Product Details:

Place of Origin:	China
Brand Name:	HONSHI
Certification:	ROHS/SGS/UL
Model Number:	3810-2XXMSXXNA01
Document:	3810-2XXMSXXNA01.pdf

Payment & Shipping Terms:

Minimum Order Quantity:	100 pieces
Price:	$0.10 - $0.35/pieces
Packaging Details:	Tray/Tube
Delivery Time:	10-15 Day
Payment Terms:	T/T,Paypal
Supply Ability:	100000kpcs

Contact Now

Detailed Product Description

Type:	DIN	Application:	PCB
Gender:	Male	Housing Material:	Brass, Nylon
Product Name:	Din 41612 Connector	Contact Material:	Brass
Rated Current:	3AMP	Contact Resistance:	20mΩ
Plated:	Gold Palted(1U")(can Customized)	Packing:	Tray
Withstand Voltage:	1000V AC/Minute	Size:	Customs
Pin:	10 - 120 Pin	Color:	Gray,Black
Highlight:	DIP Din 41612 Connector , Din 41612 Connector 3AMP , 16 Pin Male Pins Connector

2.54mm DIP Connector 2*8Pin Din41612 Connector 16Pin Male Pins Straight Through Hole PCB Connector

Product Name	Din 41612 Connector
Positions	10-160P
Row	2,3,4,5row
Current Rating	3.0AMP
Contact Resistance	30mΩ Max
Withstand Voltage	1000V AC/DC
Insulation Resistance	1000mΩ
Operation Temperature	﹣55℃ to +105℃
Contact Material	Phosphor Bronze
Contact Plating	Au And Sn over Ni
Fixing Material	Phosphor Bronze
Fixing Plating	Sn over Ni
Housing Material	PBT/PA6T(UL94V-0)

DIP Din 41612 Connector 2.54mm 16 Pin Male Pins Connector 3AMP Rated Current 0

2.54mm DIN 41612 Connector 2 Row 64Pin Right Angle dip Male Phosphor Bronze 1 Drawing:3810-2XXMSXXNA01.pdf

Item name: DIN 41612 Connector

1. The product precision and reliable performance.

2. Material: Plastic PBT and PA6T, terminal material: copper alloy.

3. DIN 41612 connectors with five rows(a, b, c,d,e) of contacts on 2.54mm square grid are available in wire-wrap or solder tail type terminations. 10pin, 15pin 20pin,30pin, 32pin 48pin 64pin 96pin and 160pin are available.

Service idea:

1. Committed to providing customers with customized, small batch, multi variety, one-stop services.

2. Quick response and effective communication, refined service timely delivery.

3. Strict implementation of the ISO 9001 and ERP system, the supply of materials strictly in accordance with the quality and standard production control.

4. Free designsupporting samples, the quality is safe and reliable, the price is competitive.

Management Concept

Responsibility Innovation Integrity Win-Win;

Team Culture

Thanksgiving Valute Respects Team efforts;

Service Purpose

Quality fisrt Customer Satisfaction Professinal Improving;

Sustainable Manner

HONSHI grow in a sustainable manner,to support our valued customers with flexibly customized interconnect solutions.
