Name: 2.54mm Pitch Pin Header Connector 5 Pin Straight With Cap Board To Board Connector
Brand: Dongguan Honshi Electronics Co., Ltd.
SKU: 1525-1105SXXXXXXNX01
Price: 0.02 USD
Availability: InStock

Home Products Board To Board Connector

2.54mm Pitch Pin Header Connector 5 Pin Straight With Cap Board To Board Connector

Product Details:

Place of Origin:	China
Brand Name:	HONSHI
Certification:	ROHS/SGS/UL
Model Number:	1525-1105SXXXXXXNX01

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$0.02 - $0.04/pieces
Packaging Details:	Tray/Tube/Reel
Delivery Time:	7-10 Day
Payment Terms:	T/T,Paypal
Supply Ability:	100000kpcs

Contact Now

Detailed Product Description

Type:	DIN	Application:	PCB
Gender:	Male	Product Name:	Pin Header Connector
Contact Material:	Brass	Rated Current:	3AMP
Contact Resistance:	20mΩ	Plated:	Gold Palted(1U")(can Customized)
Packing:	Tube/Reel	Withstand Voltage:	1000V AC/Minute
Pitch:	0.8/1.27/2.0/2.54mm	Size:	Customs
Pin:	2 - 80 Pin
Highlight:	5 Pin Board To Board Connector , Straight Board To Board Connector

Customs 2.54mm Pitch Pin Header Connector 2pin 80pin Straight Dip

Product Name	Pin Header Connector
Pitch	0.8/1.0/1.27/1.27X2.54/2.0/2.54/3.96/5.08mm
Positions	2P-100P
Current Rating	1A/2A/3A/5A/7A
Contact Resistance	20mΩ Max
Withstand Voltage	500V /1000V AC/DC
Insulation Resistance	1000mΩ Min
Operation Temperature	﹣40℃ to +105℃
Contact Material	Brass/Phosphor bronze
Contact Plating	Au Or Sn over Ni
Insulator Material	PBT/PA6T/PA9T/LCP ( UL94V-0 )

Item name: Pin Header Connector

Pin Header and Female Header Arrangement

Pin Header and Female Header connectors are important components of electronic connectors, mainly used for connecting circuit boards. Needle placement generally refers to the male head, while female placement refers to the female head. They form electrical conductivity through plug-in connections.

1. Pin Header: Pin arrangement is a component with multiple pins, and the number of pins depends on the circuit requirements. One end of the pin is a pin, and the other end usually has a soldering pin, used for soldering on a circuit board.

2. Female Header: Motherboard is a component with multiple sockets, and the number of sockets corresponds to the number of pins in the pin bank. One end of the busbar is a socket, and the other end usually has soldering pins for soldering on the circuit board.

Service idea:

1. Committed to providing customers with customized, small batch, multi variety, one-stop services.

2. Quick response and effective communication, refined service timely delivery.

3. Strict implementation of the ISO 9001 and ERP system, the supply of materials strictly in accordance with the quality and standard production control.

4. Free designsupporting samples, the quality is safe and reliable, the price is competitive.
