USB 2.0 / 3.0 Jack A Type Male Plug Connector Brass / Phosphor Bronze Contact Material

Product Details:

Place of Origin:	Guangdong, China
Brand Name:	HONSHI
Certification:	ISO9001/ISO14001/CE/ROHS/REACH
Model Number:	USB Series

Payment & Shipping Terms:

Minimum Order Quantity:	100 pieces
Price:	Negotiaiton
Packaging Details:	Tray packing
Delivery Time:	15~25Day
Payment Terms:	T/T,Paypal
Supply Ability:	1000000 Box/Boxes per Week

Contact Now

Detailed Product Description

Application:	PCB	Gender:	Female
Product Name:	USB Connector	Contact Material:	Brass/phosphor Bronze
Contact Resistance:	20mΩ	Plated:	Gold Palted(1U")(can Customized)
Packing:	Tube/Tray	Withstand Voltage:	1000V AC/Minute
Pin:	4 Pin	Color:	Black/Blue/White
Shell Material:	Copper Alloy
Highlight:	USB 2.0 Male Plug Connector , USB 3.0 Male Plug Connector

USB 2.0 /3.0 Jack A Type Male Plug Connector with Brass/Phosphor Bronze Contact Material

Product basic parameters
Model Number:	USB Series	Product Description:	2.0USB & 3.0USB Connector
Product attributes:		Material:
Insertion force:	35N MAX	Rubber core:	PBT/LCP UL94V-0
Pulling force:	10N MIN.INITIAL 8-20N AFTER	Terminal:	Brass C2680 H65, nickel base, gold plated contact point 1U
Rated current:	1.5A	Terminal:	Brass C2680 H65, nickel base, gold plated contact point 1U
Rated current:	30V	Shell:	SPCC/C2680 full area nickel plated 80 U MIN
Durability:	3000CYCLES MIN	Shell:	SPCC/C2680 full area nickel plated 80 U MIN
Voltage endurance:	500V AC MIN	Package:	100pcs/tray
Contact impedance:	300M Ω MAX INITIAL;400MΩAX	Samples Lead Time:	Free samples,customized samples 5-10Working days
Insulation resistance:	10000M Ω MIN	Application:	PCB,AV equipment,medical equipment,military communication,aerospace,phone watch electronic etc.
Working temperature:	-40 ° C to+70 ° C	Application:
All materials comply with"ROHS" environmental protection standards
Customized POGO PIN Warmly welcome W/LOW MOQ .

2.0/3.0 USB Connector

2.0 /3.0 USB connector is a universal serial bus connector that can connect two devices, such as a computer and external devices, charging devices, etc, The transmission speed is faster, much higher than the 1.0 USB connector.

USB 2.0 / 3.0 Jack A Type Male Plug Connector Brass / Phosphor Bronze Contact Material 0
